Vertical pleated insect screen MPH VERTI - pleated insect screen

The insect screen system MPH VERTI complements the offer of pleated insect screens and was designed primarily for installation on standard and roof windows.

The use of special pleated mesh, which when closing arranges in a zigzag pattern and hides in the upper profile is a characteristic feature of this product. The main advantage of the new system is the possibility of tensioning each of the cords guiding the insect screen net, which allows for its precise and even layout. It is available in several sizes, so called sets, which, depending on the needs, can be cut symmetrically, thus adjusting the pleats to the size of the window. Closing and opening of the insect screen is very easy and smooth, thanks to the system of springs installed in the bottom profile. The tensioning elements have been aesthetically hidden under a special masking profile, which can be detached and clipped in at any time. The sliding profile of the insect screen, thanks to the designed recess, allows for convenient opening and closing. It is also possible to stop the insect screen at any time. The construction of the insect screen is made of extruded aluminium guaranteeing its durability, and is based to a large extent on components of the MPH HARMONY system. Maximum size of the new insect screen is 2300×2000 mm.

It is worth adding that the MPH VERTI insect screen, due to the introduction of dedicated guide channels to the offer, also cooperates with Aluprof’s external roller shutters. For the top-mounted roller shutter system SKT OPOTERM and SKB STYROTERM system, special guide channels PPMO 60/12 and PPMO 60/17 with a dedicated chamber for mounting the MPH VERTI system were designed. Moreover, in the top-mounted roller shutter systems and front-mounted roller shutter systems, the installation of a pleated insect screen is possible with the PPMO 53 guide channel.
